Custom styles

An app can register its own style properties in Rust. A registered property works like a built-in one: it is typed into BevyStyle, accepted in style and in the hover, press and focus variants, merged per property on updates, and listed in the devtools style editor. The core's own properties are declared through the same API.

#Usage

Declare the property as a static, register it, and read its value as a component from your own systems:

<button
  style={{ sparkle: { rate: 8 } }}
  pressStyle={{ sparkle: { rate: 70, size: 7 } }}
>
  <text>Make a wish</text>
</button>

use bevy::prelude::*;
use bevy::ui::{ComputedNode, UiGlobalTransform};
use bevy_react::style::{StyleProperty, StyleValue};
use bevy_react::{ReactAppExt, ReactApplySet};

#[derive(Debug, Clone, PartialEq, serde::Deserialize, ts_rs::TS)]
pub struct Sparkle {
    /// Particles per second.
    pub rate: f32,
    /// Particle size in logical px (default `6`).
    #[ts(optional)]
    pub size: Option<f32>,
}

pub static SPARKLE: StyleProperty<Sparkle> = StyleProperty::new("sparkle");

pub struct SparklePlugin;

impl Plugin for SparklePlugin {
    fn build(&self, app: &mut App) {
        register_bindings(app);
        app.add_systems(Update, emit_sparkles.after(ReactApplySet));
    }
}

/// Also called from the `--export-bindings` path.
pub fn register_bindings(app: &mut App) {
    app.add_react_style(&SPARKLE);
}

// No writer reads `sparkle`, so its value is stamped on the node.
fn emit_sparkles(
    emitters: Query<(
        &StyleValue<Sparkle>,
        &ComputedNode,
        &UiGlobalTransform,
    )>,
) {
    for (sparkle, node, global) in &emitters {
        // spawn `sparkle.0.rate` particles per second in the node's box
    }
}

Then regenerate bevy.ts (see Typing) so sparkle type-checks. The complete property, particles included, is examples/demos/sparkle.

The light along the edge of every card in the demos app is a custom style too: spotlight is stamped the same way, and a system copies it into a UiMaterial together with the pointer position, so the light follows the cursor without a single React render (examples/demos/spotlight.rs).

#Declaring a property

A property is a static StyleProperty<T>. The static is the declaration and also the typed key: style.get(&SPARKLE) reads the merged value in a writer. Declare it static, never const: properties are identified by address.

• StyleProperty::new(name) decodes through T's serde Deserialize and types the field as T's ts-rs type. T derives both (serde and ts-rs 10, the version bevy-react uses) and is Clone + PartialEq + Debug. Doc comments on its fields carry over to the generated TypeScript.
• Every field of the struct is public, so a declaration overrides the defaults with struct-update syntax: StyleProperty { invalidate: …, ..StyleProperty::new("x") }.
• A name already registered, a core property's included, panics at startup. So does registering the same static twice.
• The value is static: a custom property accepts no { animated } binding and has no transition channel. Ease or animate in your own system if you need it.

#Codecs

The codec decides how the wire value decodes and how TypeScript types it. StyleProperty::with_codec(name, codec) (and Attribute::with_codec for element attributes) takes one of:

A value that fails to deserialize fails the whole commit: the React commit throws a TypeError and Bevy never receives its ops. The generated types are the guard. A lenient custom decoder reports the bad value instead (with bevy_react::protocol::decode_warn, which shows it in devtools) and returns Ok(None), which reads as the property being unset. A literal TS type is written into bevy.ts as is, so prefer a ts-rs type for an app property.

#Stamped values

A property that no writer reads is stamped: its value lands on the node as a StyleValue<T> component, for your systems to query:

• It is present exactly while the merged style sets the property, hover, press and focus variants included, and removed when nothing sets it. Query Without<StyleValue<T>> (or use RemovedComponents) to notice the end.
• It is updated only on a real change, so Changed<StyleValue<T>> is reliable.
• Order your systems .after(ReactApplySet) to see this frame's values.
• Two stamped properties can't share a value type, since both would be the same component. Registering them panics at startup; give one a newtype (the demo's sparkleBurst is struct SparkleBurst(f32)).
• Stamped values exist on elements with a box. A nested <text> span ignores them.

#Writers

When the property should become a component of your own shape, register a global Writer that reads it. The property is then no longer stamped:

use bevy_react::style::{StyleProperty, Writer, owns};

#[derive(Component, PartialEq)]
struct Wobble(f32);

static WOBBLE: StyleProperty<f32> = StyleProperty::new("wobble");

static WOBBLE_WRITER: Writer = Writer {
    reads: &[&WOBBLE],
    attrs: &[],
    writes: &[owns::<Wobble>],
    apply: |_ctx, style, ec| match style.get(&WOBBLE) {
        Some(&amount) => {
            ec.insert(Wobble(amount));
        }
        None => {
            ec.remove::<Wobble>();
        }
    },
};

app.add_react_style(&WOBBLE)
    .add_react_style_writer(&WOBBLE_WRITER);

• A writer re-runs only when a property it reads changes, on any styled element, including on hover, press and focus changes. On a freshly spawned node (ctx.fresh) it runs only if the style sets one of its properties.
• apply gets the full merged style, never a delta: an absent property means remove or reset.
• Each component has one writer. Claiming a component another writer writes, a core one such as BackgroundColor included, panics at registration. A global writer can't read element attributes; that is an element writer.
• Global writers run in registration order.
• WriterCtx also tells the writer the element kind, its flags, whether the node is a promoted layer root, and gives access to the assets server.

#Variants

A property in hoverStyle, pressStyle or focusStyle replaces the base value while that state is active. The replacement is whole: a variant that sets sparkle: { rate: 70 } drops every other field of the base sparkle. Keep values that must survive a state change in a separate property; the demo's click-burst key is its own sparkleBurst property for exactly this reason, since it would vanish under pressStyle right when a click lands.

#Composited layers

Inside a cached composited layer, a node's repaint is not detected from component changes. Declare what a change to the property invalidates:

use bevy_react::style::{Invalidate, Invalidation};

static WOBBLE: StyleProperty<f32> = StyleProperty {
    invalidate: Invalidate::Fixed(Invalidation::PAINT),
    ..StyleProperty::new("wobble")
};

Invalidation::PAINT makes any enclosing cached layer re-capture when the value changes. Invalidate::Computed(fn(old, new, &NodeCtx)) decides per change. Pixels your systems change later on their own (an animation driven by the value) need their own signal: push the entity into bevy_react::layer::LayerContentDirt (its nodes list) on the frames it repaints.

#Typing

The TypeScript exporter adds every app property to BevyStyle through a declare module "bevy-react" augmentation in your bevy.ts, together with the ts-rs declarations of the value types. Register the property on both paths: in the running app and in the --export-bindings exporter. A shared register_bindings(app) function called from both keeps them in step. Then regenerate bevy.ts. See TypeScript codegen.

A style key no plugin registered is dropped with an unknownStyleField warning; the rest of the style still applies.

#Limits

• No { animated } bindings and no transition easing for custom properties.
• At most 256 style properties per app, 74 of them the core's, and at most 64 global writers, 29 of them the core's.
• A malformed value decoded with plain serde loses the whole commit.
• A stamped property's value type must be unique among stamped properties.

See the style property reference for the core properties, which are declared the same way.
